Aluminium Insulated Panel

Available for customization to meet your specific requirements

• Mass Per Unit Area / (kg/m²) :＜20

• Tensile Adhesive Original Strength /MPa :≥0.10, fracture occurs in insulation material

• Tensile Adhesive Water‑Resistant Strength /MPa :≥0.10

• Tensile Adhesive Freeze‑Thaw Strength /MPa :≥0.10

• Impact Resistance /J: 10J impact qualified for ground floor, 3J impact qualified for other floors

• Bending Load /N :Not less than panel self‑weight

• Water Absorption /(g/m²):≤500

• Water Impermeability :No penetration on inner side of system

• Insulation Layer Fire‑Resistance Class: Class A

• Thermal Conductivity of Insulation Layer W/(m·k) :≤0.048

Advantages

• Premium appearance & good self‑cleaning performance: Outer face is roller‑coated fluorocarbon aluminum panel with various colors and textures. Excellent decorative effect to meet diverse architectural‑style requirements.

• Eco‑friendly & high energy‑saving: Factory‑produced modular composite panel. Full‑life‑cycle green & eco‑friendly. Built‑in energy‑saving structure provides effective thermal insulation.

• Hot‑press compound & edge‑rolling craft: One‑step online foaming and hot‑press forming ensures flat panel surface and avoids defects such as unevenness, hollowing and falling‑off from traditional cold‑bonding process. Edge‑rolled aluminum face sheet guarantees assembly precision and flatness. Double‑side fixing secures whole‑system stability.

• Light‑weight & high strength, low load‑bearing: Thin but tough composite panel. Light weight down to 5 kg per square meter, greatly reducing building load.

• Simple procedure & shorter construction period: Highly‑integrated factory production. On‑site three‑step assembly, greatly cutting construction time and site cost.
